WAGNER TITANUS User Manual

TITANUS MICRO·SENS
®
Installation
MS_A_05-en-e Data: 01/09 5 – 19
5.8.2 Function switching plan, collective connection
L1-
L1+
0V
1a
2a
3a
4a
5a
6a
7a
8a
1b
2b
3b
4b
5b
6b
7b
8b
+24V
Reset button
1a
2a
3a
4a
5a
6a
7a
8a
1b
2b
3b
4b
5b
6b
7b
8b
R
A
R
E
R
E
Alarm
L1+
L1-
Connection principle
0V
+24V
R
A
5,6 V
Line capacity
RE (E3M080 Index
< BD o. SW<V4.4x)
RE (E3M080 Index
> BD u. SW>V4.4x)
max. 250
max. 4 F
EOL2 2
Z-Diode 18V
Tra n sz orb
20V
Tra n sz orb
20V
max. 4 F
max. 150
Alarm criterion
(R )
Sie me ns
Alarm
Z-Diode
5,6 V
5,6 V
1
R
E
Line resistance
5,6 V
Alarm
Fault
Device 1 Device n
Indicator busIndicator bus
Line terminal or line
output to next device
Fault
Fig. 5.17: Collective collection of TITANUS MICRO·SENS
®
with reset button

WAGNER TITANUS Specifications

General

Power Supply	24 V DC
Operating Temperature	-20°C to +60°C
Alarm Output	Relay contacts
Certification	VdS, EN 54
Humidity Range	10% to 95% (non-condensing)
