TITANUS MICRO·SENS
®
Pipe Design
MS_A_04-en-e Data: 01/09 4 – 21
4.3.1.2 U-Pipe system
1 Pipe system
TITANUS
MICRO·SENS
P
®
P
ABCD
T
I
T
A
N
U
S
®
d
Fig. 4.6: U-Pipe system for area protection
Limit values
min. distance TITANUSP
®
P
– T piece 2 m
max. distance TITANUSP
®
P
– T piece 20 m
max. branch length 25 m
max. overall pipe length per pipe system
pipe ∅ 25 mm plus
pipe ∅ 12 mm
50 m
8 x 3 m
max. overall pipe length per pipe system with a ventila-
tor voltage of <10.5 V
pipe ∅ 25 mm plus
pipe ∅ 12 mm
40 m
8 x 3m
min. distance between 2 aspiration apertures (d) 4 m
max. distance between 2 aspiration apertures (d) 10 m
max. number aspiration apertures (n) per pipe system 8 no.
Aspiration apertures
Number of apertures
per pipe system
2 4 6 8
∅ Aspiration aperture in
mm
TP6F
7
PT)
A
B
C
D
6,0
—
—
—
4,2
4,4
—
—
3,4
3,6
3,6
—
3,0
3,0
3,2
3,2
TP
7
PT Opening diameter of the aspiration reduction film
