WAGNER TITANUS User Manual

Pipe Design TITANUS MICRO·SENS
®
4 – 10 Data: 01/09 MS_A_04-en-e
4.1.5 Design Limits
The following limit values must always be observed with the TITANUS
MICRO·SENS
P
®
P
:
• The minimum pipe length between 2 aspiration apertures is 0.1 m.
• The minimum pipe length between 2 aspiration apertures when
locating a fire is 3 m.
• The maximum pipe length between 2 aspiration apertures is 10 m.
• The maximum monitoring surface area per aspiration aperture
corresponds to the monitoring area of a point-specific alarm
according to the regulations in the particular national standards.
• Maximum 8 aspiration apertures are possible
TP0F
1
PT.
• Maximum 5 aspiration apertures are possible with site of a fire
location.
The maximum overall monitoring surface area for the TITANUS
MICRO·SENS
P
®
PP P
and the maximum overall pipe length depend on the
design chosen.
max. overall monitoring surface area
per TITANUS MICRO · SENS
P
®
P
max. design pipe lengt1F
2
PT
400 m²
Pipe ∅ 25 mm: 50 m
plus
Pipe ∅12 mm: 8 x 3 m
Because of country-specific regulations, there may be restrictions
compared to the design limits in the manual!
TP
1
PT Designs / design forms not given in the manual are to be requested.
TP
2
PT Depending on the design chosen, restricted values apply in part.
INSTRUCTION

WAGNER TITANUS Specifications

General

Power Supply	24 V DC
Operating Temperature	-20°C to +60°C
Alarm Output	Relay contacts
Certification	VdS, EN 54
Humidity Range	10% to 95% (non-condensing)
