WAGNER TITANUS User Manual

Installation TITANUS MICRO·SENS
®
5 – 18 Data: 01/09 MS_A_05-en-e
5.8 Using TITANUS MICRO·SENS
®
in the
AlgoRex
®
fire alarm system
There are various options for connecting the floating alarm and fault
contacts in the TITANUS MICRO·SENS
®
to the AlgoRex
®
fire alarm
system:
• Connection to collective lines
• Use of line components with AnalogPLUS
®
technology
• Connection using interactive line components
5.8.1 Collective Connection
The TITANUS MICRO·SENS
®
can be connected to a collective line card
(component of the central unit) in the AlgoRex
®
fire alarm system or to
other collective fire alarm central units. To do that, the alarm contact and
the fault contact are joined with a collective detection line.
Fig. 5.17
shows the preferred connections for the TITANUS MICRO·SENS
®
.
Ensure the correct polarity when 5.6 V Z diodes are used.
INSTRUCTION

WAGNER TITANUS Specifications

General

Power Supply	24 V DC
Operating Temperature	-20°C to +60°C
Alarm Output	Relay contacts
Certification	VdS, EN 54
Humidity Range	10% to 95% (non-condensing)
