WAGNER TITANUS User Manual

TITANUS MICRO·SENS
®
Maintenance
MS_A_08-en-e Data: 01/08 8 – 1
8 Maintenance
8.1 Visual check
Check whether ...
z when the pipe system is freely accessible it is firmly mounted and
undamaged.
z the aspiration apertures on the pipe system are free.
z aspiration pipe and connection cable are firmly connected.
z the TITANUS MICRO·SENS
®
is undamaged.
8.2 Testing detector and alarm forwarding
Proceed as described in Chapter 7.4 "Detection Unit and Alarm
Forwarding". Also check the detection unit visually for external dirt or
damage and if necessary make replacements.
A hardware error on the detection unit is displayed in the “Messages”
screen of the diagnosis tool.
8.3 Testing pipe system
Test the aspiration apertures on the pipe system for blockage, in areas in
which dust particles or icing may be found. If necessary, blow the pipe
system and aspiration apertures free with compressed air. Use a portable
compressed air bottle to do this (blow through device) or press the
manual blow through equipment installed on site.
Before blowing through the pipe system, separate the TITANUS
MICRO·SENS
®
from the pipe system, as otherwise the air flow sensor
will be damaged.
INSTRUCTION
ATTENTION

WAGNER TITANUS Specifications

General

Power Supply	24 V DC
Operating Temperature	-20°C to +60°C
Alarm Output	Relay contacts
Certification	VdS, EN 54
Humidity Range	10% to 95% (non-condensing)
