TITANUS MICRO·SENS
®
Pipe Design
MS_A_04-en-e Data: 01/09 4 – 11
4.2 Project planning
4.2.1 Project planning guidelines
In order to conduct project planning in accordance with the EN 54-20
standard, it is necessary to be familiar with particular factors. These are
the requirements for the system’s sensitivity, the number of aspiration
apertures and the accessories necessary for the corresponding applica-
tion. The pipe system design in conformity with the standard can be de-
termined based on these factors using the following chapter and with the
help of the project planning tables in the appendix.
4.2.1.1 Determining the necessary accessories
Since the accessory components, such as filters, have a certain influence
on the dimension of the pipe planning, the suitable accessories must be
selected for the corresponding application ahead of time. Retrofitting,
with a fine filter, for instance, is generally only possible if a more sensitive
detector module is being used or a particular reserve has been planned
in advance.
Components which have not been approved by WAGNER are used,
CE conformity on the basis of EN 54-20 will not be possible.
The following accessory components should be taken into consideration
in the process:
z Air filters
z Steam trap
z VSK stop valves
z Detector box
z OXY·SENS
®
air sampling detector
The SD-1 noise suppressor may be used in any case with no project
planning restrictions.
INSTRUCTION

WAGNER TITANUS Specifications

General

Power Supply	24 V DC
Operating Temperature	-20°C to +60°C
Alarm Output	Relay contacts
Certification	VdS, EN 54
Humidity Range	10% to 95% (non-condensing)
