3.3 Accessories – TITANUS MICRO·SENS
®
Parallel display for
TITANUS MICRO·SENS
®
Parallel display
Voltage
Nominal voltage 24V
Power consumption (at 24 V)
idle
maximum
15 mA
50 mA
electr. connection lengths max. 1000 m
Dimension
Dimensions (H x W x D mm) 70 x 140 x 200 mm
Weight
Weight 0.6 kg
Protection class
Protection class (EN 60 529) IP 54
Housing
Material Plastic (ABS)
Colour Housing papyrus white, RAL 9018
Temperature range
Parallel display – 20° to +60°C
Displays on device
Operation
Fire alarm
Action alarm
Fault
Smoke level display
Alarm location display
green operating display
red alarm display
red alarm display (optional)
yellow collective fault
yellow smoke level display 1 to 10
(10 segments) (optional)
5 red displays
(optional)
Connections
Clip strip Clips for
max. 2.5 mm² wires
Cable pair twisted,
Cable feeds
Parallel display base
Parallel display base floor
8 x M 20
2 x M 25
4 x M 25

WAGNER TITANUS Specifications

General

Power Supply	24 V DC
Operating Temperature	-20°C to +60°C
Alarm Output	Relay contacts
Certification	VdS, EN 54
Humidity Range	10% to 95% (non-condensing)
