TITANUS MICRO·SENS
®
Technical Data
MS_A_03-en-e Data: 01/09 3 – 5
Reaction indicator
Voltage
Nominal voltage
15 to 30 V DC
24 V DC
Power consumption (at 24 V)
Stand by
Blink light
Steady burning
2 mA
5 mA
8 mA
electr. connection lengths 1000 m
Protection class (EN 60 529) IP 30
Relay board
RU-1/RU-2
Dimensions 98 x 94 mm
Temperature range -40 °C to +60 °C
Contact loading capacity of the
relay contacts 1 A to 30 V DC
Power consumption (at 24 V)
RU-1
idle status
alarm status
6 mA
max. 36 mA
RU-2
idle status
alarm status
13 mA
max. 36 mA
Reset board
Power consumption max. 20 mA
Network module
Power consumption max. 40 mA
