7.3.2 Air Pressure-Dependent Adjustment
This kind of adjustment can only be carried out by using the diagnostics
tool.
A barometer
2
is required for air pressure-dependent adjustment of the air
flow sensor. The following steps must be taken:
1. Press the “Settings” button so that you can change the figures in the
diagnosis tool on the “Settings” screen.
?
TITANUS
MICRO · SENS
®
%/m
s
%
min s
m
hPa
V
0,500
10
50
140
0
1013
9,0
00000
File Record Settings Device-Selection
(Date Time)
Fault messagesStatus Settings ROOM-IDENT
Reception
Serial No.
Sensitivity (Fire alarm)
Alarm delay
Air flow range
Fault d elay
Height above sea level
Air pressure
Fan v oltage
LOGIC SENSLOGIC SENS
Set
Fault latched
ROOM-IDENT
Dynamic air flow
Set
Active Initialisation
%60Action alarm threshold
Fire alarm after
ROOM·IDENT
2. Determine the height above sea level (NN) at the aspirating smoke
detection system installation site and enter it in the “Settings“ screen.
3. Using a hand-held barometer, measure the air pressure and enter
this figure in the “Settings” screen in the diagnosis tool as well.
If this measured air pressure does not correspond to the annual average
for that height, then the air flow sensor will not adjust to 0 %.
2
Recommended: Digital precision pocket barometer GPB 1300, Greisinger electronic GmbH
INSTRUCTION
