4.3.2.4 Double-U-pipe system
1 Pipe system
TITANUS
MICRO·SENS
P
®
P
d
TIT ANUS MICRO·SENS
®
E
D
C
B
A
10
9
8
7
6
5
4
3
2
1
TITANUS
®
Fig. 4.13: Double U-pipe system, e.g. for equipment protection
Limit values
min. distance
TITANUS
P
®
P
– last T piece
2 m
max. distance
TITANUS
P
®
P
– last T piece
20 m
max. branch length 12,5 m
max. overall pipe length per pipe system
Pipe ∅ 25 mm plus
pipe ∅ 12 mm
50 m
8 x 3 m
max. overall pipe length per pipe system with a ventila-
tor voltage of <10.5 V
Pipe ∅ 25 mm plus
pipe ∅ 12 mm
40 m
8 x 3 m
max. number aspiration apertures (n) per pipe system 8 no.
minimum distance between the aspiration apertures (d) 0,1 m
maximum distance between the aspiration apertures (d) 4 m
Aspiration apertures
Number of apertures
per pipe system
4 8
∅ of all aspiration aper-
tures in mm
TP17F
18
PT)
4,4
3,0
TP
18
PT Opening diameter of the aspiration reduction film
