Maintenance TITANUS MICRO·SENS
®
8 – 2 Data: 01/09 MS_A_08-en-e
8.4 Exchanging the detection unit
1
Fig. 8.3: Exchanging the detection unit
1
With the aid of a screwdriver, loosen the four screws on the
detection unit and remove it from the device base.
2
When inserting the new detection unit, note the mechanical
coding, this protects the device against twisting. Change the
jumper X4.
3
Now with the aid of a screwdriver, screw the four screws on the
detection unit down firmly again.
4
The device initialises automatically when the jumper X4 is
changed.
