WAGNER TITANUS User Manual

TITANUS MICRO·SENS
®
Technical Data
MS_A_03-en-e Data: 01/09 3 – 3
3.2 TITANUS MICRO·SENS
®
detection box
Detection box
Voltage
Power supply (Ue)
Nominal power supply
15 to 30 V DC
24 V DC
with Bargraph and
Processor
Power consumption at idle status 30 mA
Power consumption at alarm status
fire alarm
38 mA
Power consumption at alarm status
fire alarm, smoke level
68 mA
Dimension
Dimensions (H x W x D mm) 70 x 140 x 222 mm
Weight
Weight 0.8 kg
Protection class
Protection class (EN 60 529) IP 54
Housing
Material Plastic (ABS)
Colour Housing papyrus white, RAL 9018
Temperature range
Detection box
Deep freeze version
– 20° to +60°C
– 40° to +60°C
Humidity
not condensed max. 95 % rf (without dew)
Displays on device
Operation
Fire alarm
Action alarm
Fault
Smoke level display
green operating display
red alarm display
red alarm display (optional)
yellow collective fault
yellow smoke level display 1 to 10
(10 segments) (optional)
Infrared interface
Infrared interface IR Transmitter / Receiver
Connections
Device connection Clips for
0.5 – 2.5 mm² wires
Cable pair twisted,
Cable feeds
Detection box base
Detection box base floor
8 x M 20
2 x M 25
4 x M 25
conical
pipe plug-in connections
2 x for pipe
∅ 25 mm
Reaction sensitivity
Detection unit
DM-TM-10 0.1 to 2.0 % light obscuration/m
DM-TM-50 0.5 to 2.0 % light obscuration/m

WAGNER TITANUS Specifications

General

Power Supply	24 V DC
Operating Temperature	-20°C to +60°C
Alarm Output	Relay contacts
Certification	VdS, EN 54
Humidity Range	10% to 95% (non-condensing)
