WAGNER TITANUS User Manual

Pipe Design TITANUS MICRO·SENS
®
4 – 36 Data: 01/09 MS_A_04-en-e
Line calculation The maximum line length results from the permitted line drop on the feed.
The permitted line drop is the difference resulting from the stand-by ac-
cus discharge voltage (21.5 V) and the lower operating voltage limit of
the aspiration smoke detection system.
2⋅
⋅Δ⋅
=
total
max
I
AU
L
γ
L
max
= Maximum line length in [m]
A = Wire cross-section in [mm²]
I
total = Total current of the aspiration smoke detection system in [A]
γ = Conductivity: Cu=57m/ Ω mm²
Δ U = Max.line drop on the feed
To guarantee the tightness of the housing seal, the appropriate cable
throughput for the particular cable must be selected.
z M 25- cable throughput: ∅ 9 to 14 mm
z M 20- cable throughput: ∅ 8 to 12 mm
Emergency Supply
Calculation The nominal capacity is calculated by means of the following formula:
25.1)5.0( ⋅⋅+⋅⋅= hItnIK
totalquiescentnominal
K
nominal
= nominal capacity of the emergency supply accumulators [Ah]
t = required bridging time [h]
The factor 1.25 in the equation is only to be observed if bridging times
are smaller equal to [sic] 24 hours.

WAGNER TITANUS Specifications

General

Power Supply	24 V DC
Operating Temperature	-20°C to +60°C
Alarm Output	Relay contacts
Certification	VdS, EN 54
Humidity Range	10% to 95% (non-condensing)
