1 Instrument Description
This chapter describes the instrument, including its controls, gas, and
electrical connections.
Contents:
Topic Page
Introduction 1-2
Inner source assembly 1-4
Inlets 1-6
Reference reservoir inlet 1-7
Vacuum system 1-7
MassLynx control system 1-8
Controls and indicators on the instruments’ front panel 1-9
Controls on the instruments’ top panel 1-11
Controls and connectors on instruments’ rear panel 1-12
