C-6 Calibration Reference Information

DRE calculation files

Perfluorotripentylamine for DRE

Use the FC70_EI+.drf DRE reference file for DRE calculations in EI+.

249.9840 5 532.9695 4.50 682.9600 3.5

263.9871 8.38 551.9679 100 694.9600 2.3

268.9824 5 563.9679 2.32 706.9600 3.14

280.9805 5 575.9679 1.32 732.9568 4.24

294.9866 5 582.9663 2.32 744.9568 16.64

313.9839 1.32 594.9663 1.32 782.9536 40.64

351.9807 2.5 601.9648 2.24 820.9504 2.00

413.9775 1.38 613.9630 7.00 832.9504 2.00

FC70_EI+.drf:

Calculated

m/z value

Intensity

Calculated

m/z value

Intensity

Calculated

m/z value

Intensity

68.9952 20 601.9648 0.64

180.9888 1.31

268.9824 100

513.9711 1.90

FC70_NCI-.ref: (Continued)

Calculated

m/z value

Intensity

Calculated

m/z value

Intensity

Calculated

m/z value

Intensity
