Obtaining an ion beam 3-3
Obtaining an ion beam
To obtain an ion beam:
1. In the MassLynx Tune window, click .
2. In the TDC Settings dialog box, clear the Low Mass Cut-Off check box.
See also: Low Mass Cut-Off on page B-16.
3. In the Tune window, click .
Confirm that the instrument status indicator displays green.
4. In the EI Tune tab, type the recommended starting parameter values
shown in the table below, or specify previously saved values.
5. Click View > Peak Display 2.
Result: The second peak display appears.
6. Click .
Recommended Tuning starting values:
Parameter
Recommended
EI value
Recommended
CI value
MCP Voltage 2700 2700
Source Temperature 200 120 to 150
Electron Energy 70 70
Trap Current 100 Not applicable
Ion Repeller 1 Not applicable
Emission current Not applicable 250
Beam Steering 0 0
Focus 1 70 70
Focus 2 14 14
Focus 3 40 40
