Waters GCT Premier - Controls on the Instruments Top Panel

Controls on the instruments’ top panel 1-11
Controls on the instruments’ top panel
The reference reservoir pump valve and reference inlet are located on the top
of the instrument.
Reference reservoir pump valve and reference inlet:
The reference inlet introduces volatile reference materials for instrument
tuning and calibration. Use a septum piercing-syringe to introduce reference
material through a septum located in the reference reservoir inlet cap.
See also:
• Reference reservoir maintenance on page 10-16.
• Introducing the reference sample on page 3-6.
• Reference reservoir inlet on page 1-7.
Warning: To avoid burn injuries, take care when using the reference
inlet; it can be hot.
Reference reservo
ir
pump valve
R
eference inlet
