1-10 Instrument Description
.
Tip: Any combination of LED indications not shown in these tables can
indicate a normal state or fault.
See also:
• Table titled “Vacuum LED: displays for normal instrument operation”
on page E-2.
• Table titled “Vacuum LED: displays for instrument faults” on page E-5.
• Contacting Waters on page 11-14.
Vacuum LED display:
Status Vacuum LED indication
Vented Red
Source vented, analyzer pumped Yellow
Pumped Green
Operate LED display:
Status Operate LED indication
Operate Green
Standby Red
Source solvent trip Yellow
