ENGINE
M6060, M7060, WSM
1-M17
Injector QR/ID Codes
Injectors are processed to exacting tolerances, but
there are minute variations in the amount they inject, so
to correct for these variations, a correction volume is
recorded on the QR/ID codes of the injectors.
During manufacture, the QR code is read by a
scanner and the correction value is registered in the
ECU.
9Y1210828ENM0027US0
When Replacing an Injector
Register the ID code of the replacement injector into
the ECU.
9Y1210828ENM0028US0
When Replacing the Engine ECU
Register the ID codes of all of the injectors into the
replacement engine ECU.
When replacing an ECU, as it is necessary to write
all of the data, including the injector corrections, only
KUBOTA can write the data to the ECU.
9Y1210828ENM0029US0
(1) ID Code (2) QR Code
(1) Engine ECU (2) Replacement Injector
(1) Replacement ECU (2) Injector
