ELECTRICAL SYSTEM
M6060, M7060, WSM
8-S1
1. TROUBLESHOOTING
BATTERY
STARTING SYSTEM
Symptom Probable Cause Solution
Reference
Page
All Electrical
Equipments Do Not
Operate
Battery discharged or damaged Recharge or replace G-25,
8-S8
Battery positive cable disconnected or improperly
connected
Repair or replace G-25,
1-S18,
8-S8
Battery negative cable disconnected or
improperly connected
Repair or replace G-25,
1-S18
Slow blow fuse blown Replace 8-S10,
8-S12
Fuse Blown
Frequently
Short-circuited Repair or replace 8-S10,
8-S11
Symptom Probable Cause Solution
Reference
Page
Battery Discharges
Too Quickly
Battery damaged Replace 8-S8
Alternator damaged Repair or replace 8-S18
Wiring harness disconnected or improperly
connected (between battery positive terminal and
alternator B terminal)
Repair or replace 8-M17,
8-M18
Cooling fan belt slipping Adjust tension G-28
Symptom Probable Cause Solution
Reference
Page
Starter Motor Does
Not Operate
Battery discharged or damaged Recharge or replace 8-S8,
8-S9
Slow blow fuse blown Replace 8-S10,
8-S12
Starter relay damaged Replace 8-M17,
8-M18,
8-S43
PTO switch damaged Repair or replace 8-S55
Wiring harness disconnected or improperly
connected (between main switch M terminal and
PTO switch, between main switch ST terminal
and PTO relay, shuttle neutral switch, between
safety switch and starter relay, between starter
relay and ground, between starter relay and
starter motor S terminal, between battery positive
terminal and starter motor B terminal)
Repair or replace 8-S17,
8-S56
Starter motor damaged Repair or replace 8-S17
Main switch damaged Replace 8-S14
To Next Page
