ISE User GuideUser Guide Introduction
Site Requirements
The following tables present crucial environmental requirements for the ISE Storage Blade.
Table 2: ISE Site Requirements
Environment Requirement
Operating temperature 10–35 degrees C
Operating humidity 20–80% (Non-condensing)
Operating altitude -1,000.6562–10,000 feet (-305–3,048 meters)
Heat dissipation 2,050 btu per hour
Loading weight Minimum
DataPac (varies by model) ~13–24 pounds (~5.9–10.9 kg)
Model 2400 without DataPacs ~72.3 pounds (~32.9 kg)
Model 2400 with DataPacs (2) ~97.9–120 pounds (~44.5–54.5 kg)
Power
Requirement
Input voltage 100–240 Volts AC
Input frequency 50–60 Hertz
Maximum load 10–8 Amps
Connectivity
Requirement
Host interface Eight port 8Gb FC
