Xiotech—Proprietary 160337-000 Rev D, 30 September, 2013 Page 105
Monitoring ISE User Guide
Web-Mgt System Summary
The Web-Mgt interface presents an overview of the system status on the
At-A-Glance Status Summary
view. To
display the system summary, select
System >>
display
on the navigation bar on the ISE Management window
as shown below. The summary appears (shown below). This system status is also accessible through the link
next to the ISE icon in the left navigation pane.
Figure 76. At-A-Glance Status Summary
Note. In the unlikely event that a FRU is erroneously reported as missing from an ISE ten minutes or
more after boot-up, contact
X-IO
Customer Support at 1.800.734.4716.
The current status is displayed at the top in the right corner of every Web-Mgt page and on the general ISE
status page in Orchestrator. The
Current Status
is the logical OR of all component states, representing the
overall state of the ISE system. Possible states are listed in the following table (Table 28). If the state of any
component is other than Operational, the
Current Status
field reflects that state.
State Description
Operational
All components are working satisfactorily in the system.
Uninitialized
The system must be initialized before any other activity can occur.
Warning
A component needs attention to avoid a failure.
Critical
A component has suffered a failure.
