Page 106 160337-000 Rev D, 30 September, 2013 Xiotech—Proprietary
ISE User Guide Monitoring
Table 28: Current States
The
System Information
section of the status summary display includes the items listed in the following table.
Table 29: Status Summary Description
The System Status Summary section of the
At-A-Glance Status Summary
page displays the information listed
in the following table (Table 30).
Table 30: System Status Summary
The
Event Summary
section of the
At-A-Glance Status Summary
view displays the total number of Management
Events that have occurred since the system initialization (to a maximum of approximately 2,000 events). See
“Event Logs” on page 121 for an overview of these events.
Additional ISE environmental and component detail views are available through the Web-Mgt. These other
views are accessed through the
Environment
tab (see “Environment Status” on page 108).
Status Summary Items Description
Up Time
Amount of time the system has been running since last powerup
Identifier
WWID of the ISE
Date
Current date
Time
Current system time
IP Address 1 and 2
IP addresses assigned to the Ethernet ports on the two MRCs, where address one
is that of MRC one and address two is that of MRC two.
Serial number
Unique number identifying this ISE, stored in the System Status Module (see
Figure 73 on page 102)
Model
Model number for this ISE
Vendor
Company name of the seller of this storage device
Manufacturer
Company name of the manufacturer of this storage device
Information Comment
Current Status
Overall status summary of all the physical components is displayed in the upper right corner
of most Web-Mgt panels. Displays Warning if the status of any system component is not
operational.
Individual FRU Status
Specific status for MRCs, DataPacs, Power supplies, supercapacitors, Storage Pools, and
Volumes accessed by clicking an icon in the left navigation pane.
Temperature Gauge
Overall temperature reading of the ISE, determined by the highest temperature of the col-
lective components. See “Temperature Indicators” on page 108.
