X-IO ISE-2 Series User Manual

Page 78 160337-000 Rev D, 30 September, 2013 Xiotech—Proprietary
ISE User Guide ISE Management
Web-Mgt, View Host Configuration
To view ISE host configurations, open the Detailed Host Information page as follows:
1. Select
Hosts >> summary from the navigation bar on any Web-Mgt page and the Host Summary view
opens.
2. Expand the Host navigation tree in the left navigation pane.
3. Access the
Detailed Host Information view by clicking the Host MAC ID in the expanded navigation tree
(ref. 1 in Figure 52) or the Host name in the Host Information view (ref. 2 in Figure 52).
When volume-host mappings exist, volumes mapped to the hosts are shown in the
Mapping column of the Host
Information
section.
The
Detailed Host Information page is shown below in Figure 52.
Figure 52. Detailed Host Information
Orchestrator, Modify Host Configuration
To modify the ISE host configuration using the Orchestrator, select All Devices >> ise_name >> Host View >>
Host . (See the Orchestrator User Guide.)
Web-Mgt, Modify Host Configuration
From the Detailed Host Information page (Figure 53), the following configuration changes can be made:
•Host name
• Operating system type
• Create or modify the WWID HBA ports for this host; see “Configuring Hosts” on page 60
• Create or modify a volume-host mapping scheme; see “Modify Volume–Host Mappings” on page 82
• Create or modify a comment
• Delete a host by highlighting a host and clicking
Delete at the bottom of the page
Note. A host with an active volume mapping cannot be deleted; mappings can be removed using the
Available Volumes (see 1 below) and Selected Volumes (see 2 below) section of this view.
