Page 120 160337-000 Rev D, 30 September, 2013 Xiotech—Proprietary
ISE User Guide Monitoring
System Monitoring with SNMP
The ISE provides an SNMP MIB (see “System Monitoring with SNMP” on page 120) containing the Object
Identifiers (OIDs) of ISE variables. These variables can be monitored using SNMP Get Request PDUs (see
“SNMP Setup” on page 53). The following example shows the MIB entry for ISE temperature, where N is a
company’s assigned private enterprise OID.
Figure 87. Sample MIB Entry
An SNMP Get Request with the OID in this example returns an integer representing the current temperature of
the ISE.
Performance Monitoring
The ISE includes an internal performance monitor intended to provide approximate statistics; for precise
performance monitoring, it is advisable to use external performance monitoring tools.
The Web-Mgt contains a system
Performance Information
view. To view system performance, select
Performance
>>
display
on any Web-Mgt view. The display shows the values for each of the monitored items.
Click the
Refresh
button or press
F5
to update the performance view and capture any changes to the statistics.
Figure 88. Performance Display
System performance is available through the CLI with the show performance command. To refresh the
statistics in the display, repeat the command.
The statistics are divided into three sections to provide performance characteristics from different points of
view as follows:
• System Information: Statistics by category are provided for the overall ISE and each MRC.
• Volume Information: Statistics by category are provided on a volume-by-volume basis.
• Host Information: Statistics by category are provided for each host.
In the Web-Mgt (Figure 88 on page 120), a show/hide button in the header of each display section permits
control of the view to what is most relevant. The
Display/Hide
selection remains in effect for the duration of the
browser session.
iseTemperature OBJECT-TYPE
SYNTAX Integer32
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"ISE Temperature"
::= { ise 32 } -- 1.3.6.1.4.1.N.6.1.1.1.2.32
