X-IO ISE-2 Series User Manual

Page 52 160337-000 Rev D, 30 September, 2013 Xiotech—Proprietary
ISE User Guide Initialize and Configure
CLI: To display the WOL setting from the CLI, use the show network command. To set the WOL Mode from
the CLI, use the configure --wol=<Enable|Disable> command (see Figure 13 on page 49).
System Clock Settings
During ISE manufacture, the system clock is set to Coordinated Universal Time (UTC). If desired, the Web-Mgt
or CLI, as described in this section, can be used to manually set the system clock as needed to meet site
requirements. When the system clock is set on one MRC, the system clock of the companion MRC is
automatically and immediately synchronized.
To approximately synchronize the ISE to a local server manually, enter a synchronization time and wait for the
server’s clock to cycle to that synchronization time before clicking
Save Changes in the Web-Mgt or pressing
E NTER while in the CLI.
Orchestrator: To set or change the system clock using the Orchestrator, select
All Devices >> ise_name >>
Physical View >> System Clock . (See the Orchestrator User Guide.)
Web-Mgt: To set this parameter from the Web-Mgt, select the System Clock Setup view (
System >> system
clock
).
CLI: To set this parameter from the CLI, use the configure command with the options shown in “CLI—
System Parameters” on page 49.
The following formats apply to both the Web-Mgt and the CLI:
a. Date: dd-mmm-yyyy, where mmm is the 3-letter representation of a month (for example, Nov for Novem-
ber). Enter the month in uppercase or lowercase or a combination of both; it is displayed in lowercase with
an initial capital.
b. Time: hh:mm:ss using a 24-hour clock.
c. Time Zone:
• In the Web-Mgt, a drop-down menu provides the time zone selections.
• In the CLI, type help timezone to see the time zone options.
d. Daylight: Enable this option to cause the ISE to automatically adjust the time for the change to and from
Daylight Savings Time. The Daylight option is enabled by default.
Table 14: Setting System Clock Attributes—CLI Commands
Fibre Channel Port Speed
The Fibre Channel host port speed can be set to one of the following settings:
• ISE-2, Hyper ISE, and ISE 7-Series: Speeds of 4 and 8 Gbs are supported on the individual ports when
specified otherwise all ports are the same, Fibre Channel activity occurs at the selected speed (see
support matrix at www.X-IO.com).
• Auto: Using the protocol defined in the T11 Auto-Negotiation standard, the ISE auto-negotiates with the
Fibre Channel switch to determine and set the highest port speed that both devices support.
• Auto-negotiation is enabled by default at the factory.
System Clock Attribute CLI Command
Date
configure --date=<dd-mm-yyyy>
Time
configure --time=<hh:mm:ss>
Timezone
configure --timezone=<zoneoption>
Use help timezone to
view options
Automatic Daylight
Time
configure --timezone=<zoneoption>
configure --timezone=<zoneoption> --dst
To disable
To enable
