PL 5.1 DOCUMENT ROLLS AND SENSOR
PLACES)
ITEM
1
2
3
4
S
6
7
a
9
10
11
PART
600K64650
—
50N213
23N370
62N100
22N658
..
--
-
••
130N770
DESCRIPTION
HOLD DOWN BRACKET KIT
(2/KIT) (TAG 89)
HOLD DOWN BRACKET
(P/O ITEM 1)
DOCUMENT HOLD DOWN
DRIVE ROLL
(REP 4.1.17, ADJ 4.1,2)
PLATEN GLASS
(REP 4.1.15)
IDLER ROLL
(REP 4.1.18)
DRIVE ROLL CLAMP
(NOT SPARED)
BEARING (NOT SPARED)
SPRING (NOT SPARED)
DRIVE ROLL BEARING
(NOT SPARED)
EDGE REGISTERED SENSOR
(REP 4.1.7, ADJ 4.1.2)
7356
12/97
5-7
PARTS LIST SECTION
PL 5.1
