Xerox WorkCentre 3550 Service Manual

April 2010
6-36
Phaser 3635MFP/WorkCentre 3550
dC131
General Procedures/Information
07-250 Side Registration
Tray 2 Duplex
(1st sid)e
The changed dimension of tray
2 side registration of 1st side in
duplex long and short.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-500 Top Registration
Bypass Simplex
The changed dimension of
bypass top registration in sim
-
plex.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-510 Side Registration
Bypass Simplex
The changed dimension of
bypass side registration in sim
-
plex.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-520 Top Registration
Bypass Dup_long
(2nd sid)e
The changed dimension of
bypass top registration of 2nd
side in duplex long.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-530 Side Registration
Bypass Dup_long
(2nd sid)e
The changed dimension of
bypass side registration of 2nd
side in duplex long.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-540 Top Registration
Bypass Duplex
(1st sid)e
The changed dimension of
bypass top registration of 1st
side in duplex long and short.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-550 Side Registration
Bypass Duplex
(1st sid)e
The changed dimension of
bypass side registration of 1st
side in duplex long and short.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
Table 3 NVM chain 9
Location NVM Name NVM Description Value Default
09-100 LD Light Level 600dpi laser light level. Value
in PWM.
200 to 600 350
09-110 MHV Control Bias
Control
Main charge bias control.
Basic of value (HVPS setting is
valu)e. Value in PWM.
108 to 145 126
09-120 THV Bias Control
Control
Transfer bias control. Basic of
value (HVPS setting is valu)e.
Value in PWM.
41 to 220 76
09-130 Deve Bias Control DEVE bias control. Basic of
value (HVPS setting is valu)e.
Value in PWM standard volt
-
age: --500V (PWM 522).
408 to 607 522
09-140 Detach Bias Con-
trol
Detack bias control. Basic of
value (HVPS setting is valu)e.
Value in PWM standard volt
-
age: -1800V.
80 to 160 123
09-205 Print Cartridge
Life Page Counter
Display of print cartridge pages
count.
(Read only)
09-230 Transfer Roller
Life Page Counter
Display value of pages count. (Read only)
Table 2 NVM chain 7
Location NVM Name NVM Description Value Default
Table 4 NVM chain 10
Location NVM Name NVM Description Value Default
10-200 Fuser Life Page
Counter
(Read only) Total fuser page
count
10-210 Heat Roll Life
Page Counter
(Read only) Heat roll page
count
10-220 Pressure Roll Life
Page Counter
(Read only) Pressure roll page
count
10-300 Pick-up Interval
Delay
Change the time interval for
paper pick-up.
0 to 100 msec. 0
10-310 Pick-up Interval
Delay (Special
Paper)
Change the time interval for
paper pick-up.
0 to 100 msec. 0
Table 5 NVM chain 20
Location NVM Name NVM Description Value Default
20-100 Redial Attempts Number of times to
redial.
1 to 13 7
20-110 Redial Interval Time between each
redial.
1 to 15 3
20-200 Pause Dial Time Time of each pause. 0 to 200 (1000 msec.) 4
20-210 Dial Pulse M/B
Ratio
Dial pulse make/break
ratio.
33/66 (0)
40/60 (1)
1
20-220 Auto Dial Start
Pause Time
Pause time before auto-
dialing (second)
0 to 10 seconds 1
20-300 Ring On Time Ring on time. 90 to 800msec. 90
20-310 Ring Off Time Ring off time. 90 to 800msec. 90
20-320 Ring Detection
Freq
Call indication fre-
quency range.
12 to 80Hz (1)
16 to 55Hz (2)
20 to 55hz (3)
22 to 55hz (4)
1
20-400 DTMF High-Freq
Level
DTMF high frequency
level.
0 to 15dBm 8
20-410 DTMF Low-Freq
Level
DTMF low frequency
level.
0 to 15dBm 11
20-420 DTMF Timing DTMF duration of on/off
output.
80/80 (1)
70/70 (2)
70/150 (3)
60/60 (4)
80/100 (5)
150/50 (6)
150/240 (7)
1
20-500 Dial Mode Dial mode selection. Tone (0) / Pulse (1) 0
20-510 ECM Mode ECM mode on or off. Off (0)
On (1)
0

Xerox WorkCentre 3550 Specifications

General

Print technology	-
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Duplex printing mode	Auto
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Paper input type	Paper tray
Total input capacity	550 sheets
Total output capacity	250 sheets
Total number of input trays	1
Maximum number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	60 sheets
Custom media width	148 - 210 mm
Custom media length	216 - 356 mm
Paper tray media types	Heavy paper, Lightweight paper, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 43 lbs
Auto Document Feeder (ADF) media weight (imperial)	12 - 28 lbs
Internal memory	256 MB
Maximum internal memory	512 MB
Sound power level (standby)	39 dB
Sound pressure level (printing)	55 dB
Maximum duty cycle	75000 pages per month
Page description languages	PCL 5e, PCL 6, PostScript 3
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	No
Security algorithms	802.1x RADIUS
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional x64
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	10 s
Faxing	Mono faxing
Fax memory	7 MB
Modem speed	33.6 Kbit/s
Fax forwarding to	E-mail, FTP, Fax, PC, SMB
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Product color	Blue, Grey
Market positioning	Business
Scan to	E-mail, FTP, OCR, PC, SMB, USB
Scanner type	ADF scanner
Maximum scan area	216 x 356 mm
Scan speed (black)	26 ppm
Scan speed (color)	8 ppm
Image formats supported	JPG
Document formats supported	PDF
Optical scanning resolution	300 x 300 DPI
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	60 W
Power consumption (printing)	600 W
Power consumption (PowerSave)	20 W
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Package depth	619 mm
Package width	676 mm
Package height	696 mm
Package weight	29700 g
Certification	UL, CE, FCC

Weight and Dimensions

Depth	488 mm
Width	582 mm
Height	553 mm
