April 2010
4-15
Phaser 3635MFP/WorkCentre 3550
REP 5.4
Repairs and Adjustments
7. Remove the DADF transport and feed assemblies, Figure 1.
NOTE: The DADF transport and feed assemblies are removed as a unit.
Figure 1 Transport and feed assemblies removal
8. If required, separate the DADF feed assembly from the DADF transport assembly, Figure
2.
Figure 2 Feed assembly removal
3
Remove 3 screws
at the front.
4
R
emove 1 screw beneath the DADF.
5
Lift the DADF feed and
transport assemblies out
of the DADF lower cover
assembly.
1
Remove 2 screws
at the rear.
2
Remove 1 screw
and remove the
earth lead.
2
Separate the harnesses.
3
Remove the feed assembly.
1
Separate the feed assembly
from the transport assembly by
flexing the hinges.
Document detect
sensor harness
