Xinje XD Series User Manual

123
Execution
condition
Normally ON/OFF / pulse
edge
Suitable
Models
XD, XL
Hardware
requirement
-
Software
requirement
-
64 bits
QMUL
Execution
condition
Normal ON/OFF/falling or
rising pulse edge
Suitable Models
XDH, XLH
Hardware
requirement
Version V3.7.1 or later
Software
requirement
Version V3.7.4a or
later
2) Operands
Operands
Function
Data Type
S1
The multiplication operation data address
16 bits /32 bits/64 bits,BIN
S2
The multiplication operation data address
16 bits /32 bits/64 bits,BIN
D
The result address
16 bits /32 bits/64 bits,BIN
3) Suitable soft component
Operan
ds
Word soft elements
Bit soft elements
System
Consta
nt
Modul
e
System
D
F
D
T
D
C
D
D
X
D
Y
D
M
D
S
K/H
I
D
Q
D
X
Y
M
S
T
C
Dn.
m
S1
●
●
●
●
●
●
●
●
●
S2
●
●
●
●
●
●
●
●
●
D
●
●
●
●
●
●
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD; DM
includes DM, DHM; DS includes DS, DHS. M includes M,HM,SM
；
S includes S,HS
；
T
includes T,HT
；
C includes C, HC.
<16 bits Operation>
MUL D0 D2 D4
X0
S1· S2· D·
 The contents of the two source devices are multiplied together and the result is stored at the
destination device in the format of32 bits. As the above chart: when (D0)=8, (D2)=9, (D5, D4)
=72.
 The result’s highest bit is the symbol bit: positive (0), negative (1).
 In the above example, when X0 is ON, the instruction will be executed in every scanning
period.
Description
BIN BIN BIN
(D0) × (D2) → (D5, D4)
16 bits 16 bits → 32 bits
