If constant value K, H is source soft element, they will be converted to floating number.

K500 will be converted to floating value.

The addresses of operands in EDMOV instructions must be even.
4-5-8 FlashROM Write [FWRT, DFWRT, QFWRT]
1) Summary
Write the specified data to FlashROM register.
FlashROM Write [FWRT,DFWRT,QFWRT]
16 bits
FWRT
32 bits
DFWRT
Execution
condition
Normally ON/OFF,
rising/falling edge
Suitable Models
XD, XL
Hardware
requirement
-
Software
requirement
-
64 bits
QFWRT
Execution
condition
Normal ON/OFF/falling or
rising pulse edge
Suitable Models
XDH, XLH
Hardware
requirement
Version V3.7.1 or later
Software
requirement
Version V3.7.4a or
later
2) Operands
Operands
Function
Data Type
S
The data write in the source or save in the soft
element
16 /32/64 bits, BIN
D
target soft element
16 /32/64 bits
D1
target soft element start address
16 /32/64 bits
D2
Write in data quantity
16 /32/64 bits, BIN
3) Suitable soft components
Operan
ds
Word soft elements
Bit soft elements
System
Consta
nt
Module
System
D
F
D
T
D
C
D
D
X
D
Y
D
M
D
S
K/H
I
D
Q
D
X
Y
M
S
T
C
Dn.
m
S1
●
●
●
●
●
●
●
●
●
S2
●
S
●
D
●
●
●
●
●
●
●
●
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD; DM
includes DM, DHM; DS includes DS, DHS. M includes M,HM,SM；S includes S,HS；T
includes T,HT；C includes C, HC.
Description
(K500)→(D13,D12,D11,D10)
