Xinje XD Series User Manual

447
Notes:
※ 1: HSD50 is "maintain data write back time after power failure" in v3.7.2 and above.
Appendix 3 Special Flash Register
* means it works only after repower on the PLC
I filtering
ID
Function
Description
SFD0*
Input filter time
SFD2*
Watchdog run-up time, default value is 200ms
Special function configuration
ID
Function
Description
SFD3*
Special function
configuration(default:0x0000)
Bit0:Power down memory register exception
handling.
(1) XDC series PLC only supports the
storage of 4 error history messages;
(2) This function requires programming
software version v3.5.3 (20190326) and
above.
(3) H motion mode supports up to 20
error messages, and C motion mode
supports up to 4 error messages.
HSD105~HSD109
Article 6 error message
HSD110~HSD114
Article 7 error message
HSD115~HSD119
Article 8 error message
HSD120~HD124
Article 9 error message
HSD125~HSD129
Article 10 error message
HSD130~HD134
Article 11 error message
HSD135~HSD139
Article 12 error message
HSD140~HD144
Article 13 error message
HSD145~HSD149
Article 14 error message
HSD150~HD154
Article 15 error message
HSD155~HSD159
Article 16 error message
HSD160~HSD164
Article 17 error message
HSD165~HSD169
Article 18 error message
HSD170~HSD174
Article 19 error message
HSD175~HSD179
Article 20 error message
HSD180~HSD184
Article 21 error message
H motion mode is extended to 76 error
messages (firmware version v3.7.2 and
above support)
HSD185~HSD189
Article 22 error message
……
HSD450~HSD454
Article 75 error message
HSD455~HSD459
Article 76 error message
Special FLASH data register SFD
tudonghoatoancau.com

Xinje XD Series Specifications

General

Input Voltage	24V DC
Storage Temperature	-20°C to 70°C
Protection Class	IP20
Type	PLC
Series	XD
Programming Language	Ladder Logic, Instruction List
Communication Interface	RS232, RS485
Power Supply	24V DC
Digital Inputs	Available (number varies by model)
Digital Outputs	Available (number varies by model)
Analog Inputs	Available (number varies by model)
Analog Outputs	Available (number varies by model)
Output Type	Relay, Transistor
Number of Inputs	Varies by model (see Digital Inputs and Analog Inputs)
Number of Outputs	Varies by model (see Digital Outputs and Analog Outputs)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
