Xinje XD Series User Manual

373
S2 is the mode to continue running the BLOCK. Operand: K0, K1.
K0: continue running the instructions in the BLOCK.
For example, if pulse outputting stopped last time, SBGOON will continue outputting the rest
pulse;
K1: continue running the BLOCK, but abandon the instructions have not finished last time.
Such as the pulse output instruction, if the pulse has not finished last time, SBGOON will not
continue outputting this pulse but go to the next instruction in the BLOCK.
This instruction only applies to PLSR instructions in BLOCK, and can only send the
remaining pulses for interpolation instructions, which can not be skipped.
9-6-2 The timing sequence of the instructions
SBSTOP (K1 K1) +SBGOON (K1 K1)
Function
SBGOON K1 K0
M3
S1·
S2·
↑
tudonghoatoancau.com

Xinje XD Series Specifications

General

Input Voltage	24V DC
Storage Temperature	-20°C to 70°C
Protection Class	IP20
Type	PLC
Series	XD
Programming Language	Ladder Logic, Instruction List
Communication Interface	RS232, RS485
Power Supply	24V DC
Digital Inputs	Available (number varies by model)
Digital Outputs	Available (number varies by model)
Analog Inputs	Available (number varies by model)
Analog Outputs	Available (number varies by model)
Output Type	Relay, Transistor
Number of Inputs	Varies by model (see Digital Inputs and Analog Inputs)
Number of Outputs	Varies by model (see Digital Outputs and Analog Outputs)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
