Xinje XD Series User Manual

175
<64 bits operation>
 The floating value of S1 is multiplied with the floating value point value of S2. The result of
the multiplication is stored at D as a floating value.
 If a constant K or H used as source data, the value is converted to floating point before the
multiplication operation.
 The registers in EDMUL must start with an even address.
<32 bits operation>
EMUL D100K100 D110
X1
<64 bits operation>
Note: the operand value must be floating numbers, otherwise the result will be error.
4-9-6 Floating Division[EDIV,EDDIV]
1) Summary
Floating Divide [EDIV, EDDIV]
16 bits
-
32 bits
EDIV
Execution
condition
Normally ON/OFF,
rising/falling edge
Suitable
Models
XD, XL
Hardware
requirement
-
Software
requirement
-
64 bits
EDDIV
Execution
condition
Normal ON/OFF/falling or
rising pulse edge
Execution
condition
Normal ON/OFF/falling or
rising pulse edge
(K100)× (D101,D100)→ (D111,D110)
Binary converts to Floating Binary Floating Binary Floating
(D13, D12,D11, D10)×(D23, D22,D21, D20)→(D53, D52,D51, D50)
Binary Floating Binary Floating Binary Floating
(K00)
×
(D103, D102,D101, D100)
→
(D113, D112,D111, D110)
Binary converts Binary Floating Binary Floating
to Floating
tudonghoatoancau.com

Xinje XD Series Specifications

General

Input Voltage	24V DC
Storage Temperature	-20°C to 70°C
Protection Class	IP20
Type	PLC
Series	XD
Programming Language	Ladder Logic, Instruction List
Communication Interface	RS232, RS485
Power Supply	24V DC
Digital Inputs	Available (number varies by model)
Digital Outputs	Available (number varies by model)
Analog Inputs	Available (number varies by model)
Analog Outputs	Available (number varies by model)
Output Type	Relay, Transistor
Number of Inputs	Varies by model (see Digital Inputs and Analog Inputs)
Number of Outputs	Varies by model (see Digital Outputs and Analog Outputs)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
