Xinje XD Series User Manual

64
Y6
M100
X5
X6
M11
Y6 M4 X7
M12
M13
3-5 [LDP] , [LDF] , [ANDP] , [ANDF] , [ORP] , [ORF]
Mnemonic
Function
Format and Operands
LDP
(LoaD Pulse)
Initial logical operation-Rising
edge pulse
X,Y,M,HM,SM,S,HS,T,HT,C,HC,Dn.m
LDF
(LoaD Falling
pulse)
Initial logical operation
Falling/trailing edge pulse
X,Y,M,HM,SM,S,HS,T,HT,C,HC,Dn.m
ANDP
(AND Pulse)
Serial connection of Rising edge
pulse
X,Y,M,HM,SM,S,HS,T,HT,C,HC,Dn.m
ANDF
Serial connection of
The parallel connection with OR, ORI
instructions should connect with LD,
LDI instructions in principle. But behind
the ANB instruction, it’s still ok to add a
LD or LDI instruction.
LD
X5
OR
X6
OR
M11
OUT
Y6
LDI
Y6
AND
M4
OR
M12
ANI
X7
OR
M13
OUT
M100
Relationship with ANB
Mnemonic and Function
M0
M0
M0
M0
tudonghoatoancau.com

Xinje XD Series Specifications

General

Input Voltage	24V DC
Storage Temperature	-20°C to 70°C
Protection Class	IP20
Type	PLC
Series	XD
Programming Language	Ladder Logic, Instruction List
Communication Interface	RS232, RS485
Power Supply	24V DC
Digital Inputs	Available (number varies by model)
Digital Outputs	Available (number varies by model)
Analog Inputs	Available (number varies by model)
Analog Outputs	Available (number varies by model)
Output Type	Relay, Transistor
Number of Inputs	Varies by model (see Digital Inputs and Analog Inputs)
Number of Outputs	Varies by model (see Digital Outputs and Analog Outputs)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
