Xinje XD Series User Manual

82
EDIV
Float division
4-9-6
ESQR
Float Square Root
4-9-7
SIN
Sine
4-9-8
COS
Cosine
4-9-9
TAN
Tangent
4-9-10
ASIN
Float Sine
4-9-11
ACOS
Float Cosine
4-9-12
ATAN
Float Tangent
4-9-13
Clock Operation
TRD
Read RTC data
4-10-1
TWR
Write RTC data
4-10-2
MOV
Accurate clock BD
board data read
4-10-3
TO
Accurate clock BD
board data write
4-10-4
TADD
Clock data add
4-10-5
TSUB
Clock data sub
4-10-6
HTOS
Convert hour, minute,
and second data to
seconds
4-10-7
STOH
Convert second data
to hours, minutes, and
seconds
4-10-8
TCMP
Time (hours, minutes,
seconds) compare
4-10-9
DACMP
Date (year, month,
day) compare
4-10-10
4-2 Reading Method of Applied Instructions
In this manual, the applied instructions are described in the following manner.
1)Summary
ADDITION [ADD]
16 bits
ADD
32 bits
DADD
Execution
condition
Normally ON/OFF,
Rising/Falling edge
Suitable
Models
XD, XL
Hardware
requirement
-
Software
requirement
-
EDIV S1 S2 D
ESQR S D
SIN S D
COS S D
TAN S D
ASIN S D
ACOS S D
ATAN S D
TRD D
TWR D
