Xinje XD Series User Manual

340
Or click the source file / header file to be exported in the project column on the left, and click
"export" in the editing interface on the right:
Select the export mode (editable or not) in the pop-up file information.
Click OK after setting and select the file saving path.
After selecting the path, click OK to complete the export.
8-8-6 Import
8-8-6-1 Import the function library
Select "Function Library" in the "Project" toolbar on the left, right-click and select "Import to
Project Library" or "Import to Global Library":
In the pop-up "select function library file" interface, select a file and click "open" to complete
the import.
tudonghoatoancau.com

Xinje XD Series Specifications

General

Input Voltage	24V DC
Storage Temperature	-20°C to 70°C
Protection Class	IP20
Type	PLC
Series	XD
Programming Language	Ladder Logic, Instruction List
Communication Interface	RS232, RS485
Power Supply	24V DC
Digital Inputs	Available (number varies by model)
Digital Outputs	Available (number varies by model)
Analog Inputs	Available (number varies by model)
Analog Outputs	Available (number varies by model)
Output Type	Relay, Transistor
Number of Inputs	Varies by model (see Digital Inputs and Analog Inputs)
Number of Outputs	Varies by model (see Digital Outputs and Analog Outputs)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
