Special relays are some relays which are defined with special meanings or functions, start
from SM0.
There are two functions for special relays, first is used to drive the coil, the other type is
forspecial running.
E.g.: SM2 is the initial pulse, activates only at the moment of start
SM34 is “all output disabled”
Special auxiliary relays can’t be used as normal relay M;
Note: The range of soft components mentioned above is the valid range of PLC in the X-NET
communication mode. In the MODBUS communication mode, some relays can not read and
write. The specific usable range is shown in chapter 6-2-3.
2-6 Status Relay (S, HS)
Status relays addresses of XD/XL series PLC are in form of decimal, the address are shown
below:
Series
Name
Range
Normal
Power-off holding
XD1/XD2/XD3
S
HS
S0~S1023
HS0~HS127
XD5/XDM/XDC/XD5E/XDME
S0~S7999
HS0~HS999
XDH
S0~S19999
HS0~HS1999
XL1/XL3
S0~S1023
HS0~HS127
XL5/XL5E/XLME
S0~S7999
HS0~HS999
XLH
S0~S19999
HS0~HS1999
Status relays S and HS are very import in ladder program; they are used together with
instruction “STL” in the flow. The flow can make the program clear and easy to modify.
 For common use
After shut off the PLC power, S relays will be OFF
 For Power Off Retentive Use
HS relays can keep the ON/OFF status even PLC power is off
 The status relays also have countless “normally ON/OFF” contactors. So users can use
them freely in the program.
Note: The range of soft components mentioned above is the valid range of PLC in the X-NET
communication mode. In the MODBUS communication mode, some relays can not read and
write. The specific usable range is shown in chapter 6-2-3.
Address List
Function
tudonghoatoancau.com

Xinje XD Series Specifications

General

Input Voltage	24V DC
Storage Temperature	-20°C to 70°C
Protection Class	IP20
Type	PLC
Series	XD
Programming Language	Ladder Logic, Instruction List
Communication Interface	RS232, RS485
Power Supply	24V DC
Digital Inputs	Available (number varies by model)
Digital Outputs	Available (number varies by model)
Analog Inputs	Available (number varies by model)
Analog Outputs	Available (number varies by model)
Output Type	Relay, Transistor
Number of Inputs	Varies by model (see Digital Inputs and Analog Inputs)
Number of Outputs	Varies by model (see Digital Outputs and Analog Outputs)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
