4-7-2 Logic shift left [LSL], Logic shift right [LSR]
1) Summary
Do logic shift right/left for the data
Logic shift left [LSL, DLSL]
16 bits
LSL
32 bits
DLSL
Execution
condition
Normally ON/OFF,
rising/falling edge
Suitable
Models
XD, XL
Hardware
requirement
-
Software
requirement
-
Logic shift right [LSR,DLSR]
16 bits
LSR
32 bits
DLSR
Execution
condition
Normally ON/OFF,
rising/falling edge
Suitable
Models
XD, XL
Hardware
requirement
-
Software
requirement
-
2) Operands
Operands
Function
Data Type
D
Source data address
16 bits/32 bits, BIN
n
Arithmetic shift left/right times
16 bits/32bit, BIN
3) Suitable soft components
Operan
ds
Word soft elements
Bit soft elements
System
Consta
nt
Modul
e
System
D
F
D
T
D
C
D
D
X
D
Y
D
M
D
S
K/H
I
D
Q
D
X
Y
M
S
T
C
Dn.
m
D
●
●
●
●
●
●
●
n
●
