Xinje XD Series User Manual

118
4-6 Data Operation Instructions
Mnemonic
Function
Chapter
ADD
Addition
4-6-1
SUB
Subtraction
4-6-2
MUL
Multiplication
4-6-3
DIV
Division
4-6-4
INC
Increment
4-6-5
DEC
Decrement
4-6-5
MEAN
Mean
4-6-6
WAND
Logic Word And
4-6-7
WOR
Logic Word Or
4-6-7
WXOR
Logic Exclusive Or
4-6-7
CML
Compliment
4-6-8
NEG
Negation
4-6-9
4-6-1 Addition [ADD, DADD, QADD]
1) Summary
Add two numbers and store the result
Add [ADD,DADD, QADD]
16 bits
ADD
32 bits
DADD
Execution
condition
Normal ON/OFF/falling or
rising pulse edge
Suitable Models
XD, XL
Hardware
requirement
-
Software
requirement
-
64 bits
QADD
Execution
condition
Normal ON/OFF/falling or
rising pulse edge
Suitable Models
XDH, XLH
Hardware
requirement
Version V3.7.1 or later
Software
requirement
Version V3.7.4a or
later
2) Operands
Operands
Function
Data Type
Three operands
S1
The add operation data address
16 bits/32 bits/64 bits, BIN
S2
The add operation data address
16 bits/32bit/64 bits, BIN
D
The result address
16 bits/32bit/64 bits, BIN
Two operands
D
Be Added data and result data address
16 bits/32 bits/64 bits, BIN
S1
Add data address
16 bits/32 bits/64 bits, BIN
