Xinje XD Series User Manual

146
4-8-3 Integer converts to float point [FLT, DFLT,FLTD]
1)Summary
bit integer converts to float point [FLT, DFLT,FLTD]
16 bits
FLT
32 bits
DFLT
64 bits
FLTD
Execution
condition
Normally ON/OFF,
rising/falling edge
Suitable
Models
XD, XL
Hardware
requirement
-
Software
requirement
-
2) Operands
Operands
Function
Data Type
S
Source soft element address
16 bits/32 bits/64 bits,BIN
D
Target soft element address
32 bits/64 bits,BIN
3) Suitable soft components
Operan
ds
Word soft elements
Bit soft elements
System
Consta
nt
Modul
e
System
D
F
D
T
D
C
D
D
X
D
Y
D
M
D
S
K/H
I
D
Q
D
X
Y
M
S
T
C
Dn.
m
S
●
●
D
●
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD; DM
includes DM, DHM; DS includes DS, DHS. M includes M, HM, SM; S includes S, HS; T
includes T, HT; C includes C, HC.
<16 bits instruction>
<32 bits instruction >
DFLT D10 D12
S· D·
X0
<64 bits instruction>
FLTD D10 D14
S· D·
X0
 Convert BIN integer to binary floating point. As the constant K, H will auto convert by the
floating operation instruction, so this FLT instruction can’t be used.
Description
(D10) → (D13,D12)
BIN integer Binary float point
FLT D10 D12
S· D·
X0
(D11,D10) → (D13,D12)
BIN integer Binary float point
(D13,D12,D11,D10) → (D15,D14)
BIN integer Binary float point
