Xinje XD Series User Manual

55
 BIN: BINARY NUMBER
Inside the PLC, all the numbers will be processed in binary. But when monitoring on the
device, all the binary will be transformed into HEX or DEC.
 OCT: OCTAL NUMBER
XD/XL series PLC I/O relays are in octal. Such as [X0-7, X10-17,….X70-77].
 BCD: BINARY CODE DECIMAL
BCD uses 4 bits binary number to represent decimal number 0-9. BCD can be used in 7
segments LED and BCD output digital switch
 Other numbers ( float number)
XD/XL series PLC can calculate high precision float numbers. It is calculated in binary
numbers, and display in decimal numbers.
PLC program should use K, H to process values. K means decimal numbers, H means hex
numbers. Please note the PLC input/output relay use octal address.
 Constant K
K is used to display decimal numbers. K10 means decimal number 10. It is used to set timer
and counter value, operand value of applied instruction.
 Constant H
H is used to display hex numbers. HA means decimal number 10. It is used to set operand
value of applied instruction.
 Constant B
B is used to display binary numbers. B10 means decimal number 2. It is used to set operand
value of applied instruction.
2-12 Programming principle
Sign P and I
P is the program sign for condition and subprogram jump.
I is the program sign for interruption (external interruption, timer interruption, high speed
counter interruption, precise time interruption…).
P and I addresses are in decimal. Please refer to the following table:
Series
Sign
Address
XD, XL
P
P0~P9999
Display
tudonghoatoancau.com

Xinje XD Series Specifications

General

Input Voltage	24V DC
Storage Temperature	-20°C to 70°C
Protection Class	IP20
Type	PLC
Series	XD
Programming Language	Ladder Logic, Instruction List
Communication Interface	RS232, RS485
Power Supply	24V DC
Digital Inputs	Available (number varies by model)
Digital Outputs	Available (number varies by model)
Analog Inputs	Available (number varies by model)
Analog Outputs	Available (number varies by model)
Output Type	Relay, Transistor
Number of Inputs	Varies by model (see Digital Inputs and Analog Inputs)
Number of Outputs	Varies by model (see Digital Outputs and Analog Outputs)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
