Xinje XD Series User Manual

211
3)Suitable Soft Components
Operands
Word soft elements
Bit soft elements
System
Constant
Module
System
D
FD
TD
CD
DX
DY
DM
DS
K/H
ID
QD
X
Y
M
S
T
C
Dn.m
S1
Only can be HSC
S2
●
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD;
DM includes DM, DHM; DS includes DS, DHS. M includes M,HM,SM；S includes S,HS；
T includes T,HT；C includes C, HC.
 When M0 is on, HSC0 counts X0 signal in single phase mode, compares the high-speed
counting value with the value set in register D20. When the high-speed counting value is
equal to the set value, HSC0 coil is set on immediately, and the counting value is
accumulated in HSCD0 (double words).
 If countings complete and the driving condition M0 is not disconnected, HSC0 will
remain ON state and continue counting, and the counting value in HSCD0 will continue
to accumulate.
 If countings complete and the driving condition M0 is disconnected, HSC0 will remain on
state and the counting value in HSCD0 will remain unchanged.
 During the counting process, if M0 is disconnected and connected again, the values in
HSCD0 will continue to accumulate after the last counting value.
 In the counting process, if the setting value in D20 changes and the current counting value
is less than the new setting value, then the new setting value is compared.
 The edge mode of single-phase high-speed counting can be set using SFD310 to SFD313
(corresponding to HSC0 to HSC6 respectively). Take HSC0 as an example, SFD310 is 0:
rising edge count; 1: indicates falling edge counting; 2: indicates that both rising and
falling edges count.
Note: This function is supported only by PLC firmware version V3.4.6 and later.
5-7-2 AB phase HSC [CNT_AB]
1)Instruction Summary
AB phase HSC instruction.
AB phase HSC [CNT_AB]
16 bits Instruction
-
32 bits Instruction
CNT_AB
Execution condition
Normally ON/OFF
coil
Suitable models
XD, XL(exclude XD1,
XL1)
Hardware
-
Software
-
FUNCTIONS AND ACTIONS
