Xinje XD Series User Manual

213
As shown above, when M0 is ON, HSC0 begins to count the pulse input of X0 port; when M1
changes fromOFF to ON, HSC0 is reset, and the count value in HSCD0 (double words) is
cleared.
5-7-4 Read HSC value [DMOV]
1)Instruction Summary
Read HSC value to the specified register;
Read HSC value [DMOV]
16 bits Instruction
-
32 bits Instruction
DMOV
Execution
condition
Normally ON/OFF,
rising/falling edge
Suitable models
XD, XL (exclude
XD1, XL1)
Hardware
requirement
Software
requirement
-
2)Operands
Operands
Function
Type
S
Specify HSC code
32 bits, BIN
D
Specify the read/written register
32 bits, BIN
3)Suitable Soft Components
Operands
Word soft elements
Bit soft elements
System
Constant
Module
System
D
FD
TD
CD
DX
DY
DM
DS
K/H
ID
QD
X
Y
M
S
T
C
Dn.m
S1
Only can be HSC
S2
●
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD;
DM includes DM, DHM; DS includes DS, DHS. M includes M,HM,SM；S includes S,HS；
T includes T,HT；C includes C, HC.
DMOV HSC0 D10
S. D.
 When the trigger condition is established, the high-speed count value in the accumulative
register HSCD0 (double words) corresponding to HSC0 of the high-speed counter is read
into the data register D10 (double words).
 High-speed counter can not directly participate in any application instructions or data
comparison instructions (such as DMUL, LD > etc.) except DMOV, but can only be carried
out after reading and writing into other registers.
 As high speed counter is double words counter, so it must use 32-bit instruction DMOV.
 DMOV often uses together with high speed counter.
Program example:
FUNCTIONS AND ACTIONS
tudonghoatoancau.com

Xinje XD Series Specifications

General

Input Voltage	24V DC
Storage Temperature	-20°C to 70°C
Protection Class	IP20
Type	PLC
Series	XD
Programming Language	Ladder Logic, Instruction List
Communication Interface	RS232, RS485
Power Supply	24V DC
Digital Inputs	Available (number varies by model)
Digital Outputs	Available (number varies by model)
Analog Inputs	Available (number varies by model)
Analog Outputs	Available (number varies by model)
Output Type	Relay, Transistor
Number of Inputs	Varies by model (see Digital Inputs and Analog Inputs)
Number of Outputs	Varies by model (see Digital Outputs and Analog Outputs)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
