Xinje XD Series User Manual

448
0: the system clears it;
1: No processing.
Bit1: Execute user program in external
interrupt subroutine.
0: execute in task;
1: Execute in interrupt (in this mode, the user
interrupt subroutine cannot contain C
language function block). This mode is
generally used in occasions that require high
real-time performance of external signals.
Bit2: whether to raise the external interrupt
priority.
0: not raise;
1: raise (raise to the highest).
I Mapping
ID
Function
Description
SFD10*
I00 corresponds to X**
Input terminal 0
corresponds to X** number
0xFF means terminal
bad，0xFE means
terminal idle
SFD11*
I01 corresponds to X**
SFD12*
I02 corresponds to X**
……
……
SFD73*
I77 corresponds to X**
Default value is
77(Octonary)
O Mapping
ID
Function
Description
SFD74*
O00 corresponds to
Y**
Output terminal 0 correspond
to Y** number，Default value
is 0
0xFF means terminal
bad，0xFE means
terminal idle
……
……
SFD137
*
O77 corresponds to
Y**
Default value is 77(Octonary)
I Attribute
ID
Function
Description
SFD138*
I00 attribute
Attribute of input terminal 0
0：positive logic
others
：
negative
logic
SFD139*
I01 attribute
……
……
SFD201*
I77 attribute
High Speed Counting
ID
Function
Description
SFD310
HSC0 single phase counting
edge configuration
0: rising edge count,
1: Falling edge count,
2: Both rising and falling edges are counted
tudonghoatoancau.com

Xinje XD Series Specifications

General

Input Voltage	24V DC
Storage Temperature	-20°C to 70°C
Protection Class	IP20
Type	PLC
Series	XD
Programming Language	Ladder Logic, Instruction List
Communication Interface	RS232, RS485
Power Supply	24V DC
Digital Inputs	Available (number varies by model)
Digital Outputs	Available (number varies by model)
Analog Inputs	Available (number varies by model)
Analog Outputs	Available (number varies by model)
Output Type	Relay, Transistor
Number of Inputs	Varies by model (see Digital Inputs and Analog Inputs)
Number of Outputs	Varies by model (see Digital Outputs and Analog Outputs)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
