Xinje XD Series User Manual

449
SFD311
HSC2 single phase counting
edge configuration
0: rising edge count,
1: Falling edge count,
2: Both rising and falling edges are counted
SFD312
HSC4 single phase counting
edge configuration
0: rising edge count,
1: Falling edge count,
2: Both rising and falling edges are counted
SFD313
HSC6 single phase counting
edge configuration
0: rising edge count,
1: Falling edge count,
2: Both rising and falling edges are counted
SFD320
HSC0 frequency times
2：2 times frequency;
4: 4 times frequency(effective at AB phase
counting mode)
SFD321
HSC2 frequency times
Ditto
SFD322
HSC4 frequency times
Ditto
SFD323
HSC6 frequency times
Ditto
SFD324
HSC8 frequency times
Ditto
SFD325
HSC10 frequency times
Ditto
SFD326
HSC12 frequency times
Ditto
SFD327
HSC14 frequency times
Ditto
SFD328
HSC16 frequency times
Ditto
SFD329
HSC18 frequency times
Ditto
SFD330
Bit selection of HSC
absolute and relative(24
segment)
bit0 corresponds to HSC0，bit1corresponds to
HSC2
，
and so on, bit9 corresponds to HSC18
0
：
relative
1：absolute
SFD331
Interrupt circulating of 24
segments high speed
counting
bit0 corresponds to HSC0，bit1corresponds to
HSC2
，
and so on, bit9 corresponds to HSC18
0
：
single
1：loop
SFD332
CAM function
bit0 corresponds to HSC0
，
bit1corresponds to
HSC2，and so on, bit9 corresponds to HSC18
0：do not support CAM function
1
：
support CAM function
Expansion Module Configuration
ID
Function
Explanation
SFD340
Extension module configuration
status(#1#2)
Configuration Status of Extension
Modules 1 and 2
SFD341
Extension module configuration
status(#3#4)
Configuration Status of Extension
Modules 3 and 4
……
……
……
SFD347
Extension module configuration
status(#15#16)
Configuration Status of Extension
Modules 15 and 16
SFD348
BD module configuration status(#1#2)
Configuration Status of BD Modules
1 and 2
SFD349
ED module configuration status(#1)
Configuration Status of ED Module 1
SFD350
Extension module configuration
Configuration of Extension Module 1
...
SFD359
tudonghoatoancau.com

Xinje XD Series Specifications

General

Input Voltage	24V DC
Storage Temperature	-20°C to 70°C
Protection Class	IP20
Type	PLC
Series	XD
Programming Language	Ladder Logic, Instruction List
Communication Interface	RS232, RS485
Power Supply	24V DC
Digital Inputs	Available (number varies by model)
Digital Outputs	Available (number varies by model)
Analog Inputs	Available (number varies by model)
Analog Outputs	Available (number varies by model)
Output Type	Relay, Transistor
Number of Inputs	Varies by model (see Digital Inputs and Analog Inputs)
Number of Outputs	Varies by model (see Digital Outputs and Analog Outputs)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
