Xinje XD Series User Manual

137
Hardware
requirement
-
Software
requirement
-
2) Operands
Operands
Function
Data Type
D
Source data address
16 bits/32 bits, BIN
n
Shift right or left times
16 bits/32 bits, BIN
3)Suitable soft components
Operan
ds
Word soft elements
Bit soft elements
System
Consta
nt
Modul
e
System
D
F
D
T
D
C
D
D
X
D
Y
D
M
D
S
K/H
I
D
Q
D
X
Y
M
S
T
C
Dn.
m
D
●
●
●
●
●
●
●
n
●
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD;
DM includes DM, DHM; DS includes DS, DHS. M includes M,HM,SM;S includes S,HS;T
includes T,HT;C includes C, HC.
 When X0 changes from OFF to ON, the value will be cycle moved left or right, the last bit is
stored in carry flag.
< Cycle shift left> < Cycle shift right>
Description
