Xinje XD Series User Manual

161
Ignore the 1 of M11
3) Suitable soft components
Operan
ds
Word soft elements
Bit soft elements
System
Constant
Module
System
D
F
D
T
D
C
D
D
X
D
Y
D
M
D
S
K/H
I
D
QD
X
Y
M
S
T
C
Dn.m
S
●
●
●
●
●
●
●
●
●
●
●
●
●
●
D
●
●
●
●
●
●
n
●
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD; DM
includes DM, DHM; DS includes DS, DHS. M includes M, HM, SM; S includes S, HS; T
includes T, HT; C includes C, HC.
< When is bit device > n≤16
M10ENCO D10 K3
X0
n
S· D·

If the number of bits in the source address is 1, the low side is ignored, and if the source
address is 0, the instruction will not be executed.

When the driving condition is OFF, the instruction is not executed and the coding output is
unchanged.

When n = 16, if the encoding instruction is a bit element, its point number is 2 ^ 16 = 65536.

N = 3, the encoded object has 2
3
= 8 bits, which are M17 ~ M10, and the encoding results are
stored in the lower three bits of D10, which are bit2 ~ bit0.

M13 and M11 are both 1. Ignoring M11, M13 is coded, bit2-bit0 represent 3, while bit0 and
bit1 are 1.
< When is word device n≤4
D0ENCO D1 K3
X1
n
S· D·
Description
S·
S·
tudonghoatoancau.com

Xinje XD Series Specifications

General

Input Voltage	24V DC
Storage Temperature	-20°C to 70°C
Protection Class	IP20
Type	PLC
Series	XD
Programming Language	Ladder Logic, Instruction List
Communication Interface	RS232, RS485
Power Supply	24V DC
Digital Inputs	Available (number varies by model)
Digital Outputs	Available (number varies by model)
Analog Inputs	Available (number varies by model)
Analog Outputs	Available (number varies by model)
Output Type	Relay, Transistor
Number of Inputs	Varies by model (see Digital Inputs and Analog Inputs)
Number of Outputs	Varies by model (see Digital Outputs and Analog Outputs)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
