Xinje XD Series User Manual

253
Type
component
Address
numbers
Modbus
address
(hex)
Modbus
address
(decimal)
ID20000~ID20099(#1
BD)
100
58D0~5933
22736~22835
ID20100~ID20199(#2
BD)
100
5934~5997
22836~22935
ID30000~ID30099(#1
ED)
100
5BF0~5C5
3
23536~23635
QD
QD0~QD99(main unit)
100
6000~6063
24576~24675
QD10000~QD10099(#1
module)
100
6100~6163
24832~24931
QD10100~QD10199(#2
module)
100
6164~61C7
24932~25031
QD10200~QD10299(#3
module)
100
61C8~622
B
25032~25131
QD10300~QD10399(#4
module)
100
622C~628F
25132~25231
QD10400~QD10499(#5
module)
100
6290~62F3
25232~25331
QD10500~QD10599(#6
module)
100
62F4~6357
25332~25431
QD10600~QD10699(#7
module)
100
6358~63B
B
25432~25531
QD10700~QD10799(#8
module)
100
63BC~641
F
25532~25631
QD
QD10800~QD10899(#9
module)
100
6420~6483
25632~25731
QD10900~QD10999(#1
0 module)
100
6484~64E7
25732~25831
QD11000~QD11099(#1
1 module)
100
64E8~654
B
25832~25931
QD11100~QD11199(#1
2 module)
100
654C~65A
F
25932~26031
QD11200~QD11299(#1
3 module)
100
65B0~6613
26032~26131
QD11300~QD11399(#1
4 module)
100
6614~6677
26132~26231
QD11400~QD11499(#1
5 module)
100
6678~66D
B
26232~26331
QD11500~QD11599(#1
6 module)
100
66DC~673
F
26332~26431
QD20000~QD20099(#1
BD)
100
68D0~6933
26832~26931
QD20100~QD20199(#2
BD)
100
6934~6997
26932~27031
QD30000~QD30099(#1
ED)
100
6BF0~6C5
3
27632~27731
SD
SD0~SD4095
4096
7000~7FFF
28672~32767
TD
TD0~TD4095
4096
8000~8FFF
32768~36863
CD
CD0~CD4095
4096
9000~9FFF
36864~40959
ETD
ETD0~ETD39
40
A000~A02
7
40960~40999
tudonghoatoancau.com

Xinje XD Series Specifications

General

Input Voltage	24V DC
Storage Temperature	-20°C to 70°C
Protection Class	IP20
Type	PLC
Series	XD
Programming Language	Ladder Logic, Instruction List
Communication Interface	RS232, RS485
Power Supply	24V DC
Digital Inputs	Available (number varies by model)
Digital Outputs	Available (number varies by model)
Analog Inputs	Available (number varies by model)
Analog Outputs	Available (number varies by model)
Output Type	Relay, Transistor
Number of Inputs	Varies by model (see Digital Inputs and Analog Inputs)
Number of Outputs	Varies by model (see Digital Outputs and Analog Outputs)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
