Xinje XD Series User Manual

263
Input coil read[INPR]
16 bits
instruction
INPR
32 bits
instruction
-
Execution
condition
Normally ON/OFF, rising
edge
Suitable
models
XD, XL
Hardware
requirement
-
Software
requirement
-
2)Operands
Operands
Function
Type
S1
Specify remote communication station no.
16 bits, BIN
S2
Specify remote coil start address number
16 bits, BIN
S3
Specify coil number
16 bits, BIN
D1
Specify start address number of local receipt
coils
bit
D2
Specify serial port number
16 bits, BIN
3)Suitable soft components
Operands
Word soft elements
Bit soft elements
System
Constant
Module
System
D
F
D
T
D
C
D
D
X
D
Y
D
M
D
S
K/H
I
D
Q
D
X
Y
M
S
T
C
Dn.
m
S1
●
●
●
●
●
S2
●
●
●
●
●
S3
●
●
●
●
●
D1
●
●
●
●
●
●
D2
K
Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD;
DM includes DM, DHM; DS includes DS, DHS. M includes M, HM, SM; S includes S
and HS; T includes T and HT; C includes C and HC.
INPR K1 K500 K3 M1
X0
K2
S1· S2· S3· D1· D2·
 Read input coil, Modbus function code is 02H.
 Serial port: K0~K5. K0: Port0 (RS232), K1: Port1(RS232), K2: Port2(RS485), K3:
Port3(left extension port), K4: Port4(above extension port 1), K5: Port5(above
extension port 2).
 Operand S3: K1~K2000, max input coil number is 2008.
 When X0 is ON, INPR instruction is executed, Modbus read write flag SM160(serial
port2) is set ON, SM160 is set OFF when the execution is completed. If a
communication error occurs and the number of resend is set, it will be automatically
resend. Users can check the relevant registers to determine the cause of the error. The
execution result of Modbus read and write instructions of serial port 2 is in SD160.
Function
